Vehicle Information
VIN:
1FTSF21Y09EA52669
Stock #:
ABBT50674
Model Code:
F21
Highlighted Features
Feature availability subject to final vehicle configuration. Please reference window sticker for more info.
-
4WD/AWD
All Features
- Manual transfer case & hubs
- 4-wheel drive
- 72 amp/hr (650 CCA) battery
- 157-amp HD alternator
- Trailer tow pkg-inc: 7-wire harness w/relays, 7/4 pin combination connector
- 12.5K Built Ford Tough trailer hitch receiver-inc: 2" hitch
- 8' pickup box-inc: (6) tie-down hooks, partitionable & stackable storage
- (2) front tow hooks
- Mono-beam front axle w/coil spring suspension
- HD gas shock absorbers
- Front stabilizer bar
- Pwr steering w/steering damper
- Pwr 4-wheel disc brakes w/vacuum boost
- 2-ton mechanical jack
- (5) LT245/75R17E all-season BSW tires
- 17" argent painted steel wheels w/painted center ornaments
- Full-size spare tire w/lock & carrier
- Black painted steel front bumper w/grained mold-in-color top cover
- Black painted rear bumper
- Black lower air dam
- Front fender vents
- Box-rail & tailgate top-edge moldings
- Black painted grille
- Sealed beam halogen headlamps
- Pickup box/cargo lights
- Manual telescoping trailer tow mirrors w/manual glass
- Solar tinted glass
- Interval windshield wipers
- Front license plate bracket
- Rear license plate bracket
- Black door handles
- Removable locking tailgate w/black handle & Tailgate Assist
- AM/FM stereo-inc: digital clock, (2) speakers
- HD vinyl bench seat w/recline & integrated armrest -inc: cupholders in armrest (w/213 ESOF Transfer Case, REQ: 445 or 447 Manual Trans)
- Black vinyl full-floor covering
- Carpet delete
- Color-keyed scuff plates
- SecuriLock anti-theft ignition
- Manual air conditioning
- (4) air registers w/positive shut-off
- Auxiliary pwr point
- Dash-top tray
- Glove box
- Instrument panel mounted storage bin & trash bag hook
- Color-keyed molded door trim panel-inc: hard armrest, grab handle, reflector
- Color-keyed cloth headliner
- Front passenger-side roof ride handle
- Driver & passenger grab handles
- Dual color-keyed cloth sunvisors-inc: driver-side pocket, passenger-side mirror insert
- Door operated dome lamp w/time delay off & IP switch
- Map lamps
- Dual color-keyed coat hooks
- 4-wheel anti-lock braking system (ABS)
- Driver & front passenger airbags w/passenger-side deactivation switch
- SOS post crash alert system -inc: doors unlock, horn & hazard flashers are activated when air bags are deployed
- Color-keyed safety belts w/height adjustable D-rings
- BeltMinder seatbelt-not-buckled chime & flashing warning light
- Child seat tethers on passenger seat
- Tire pressure monitoring system
- 3.73 axle ratio (REQ: 995 Engine)
- Stationary elevated engine idle control (SEIC)
- Manual transfer case & hubs
- 4-wheel drive
- 72 amp/hr (650 CCA) battery
- 157-amp HD alternator
- Trailer tow pkg-inc: 7-wire harness w/relays, 7/4 pin combination connector
- 12.5K Built Ford Tough trailer hitch receiver-inc: 2" hitch
- 8' pickup box-inc: (6) tie-down hooks, partitionable & stackable storage
- (2) front tow hooks
- Mono-beam front axle w/coil spring suspension
- HD gas shock absorbers
- Front stabilizer bar
- Pwr steering w/steering damper
- 2-ton mechanical jack
- 17" argent painted steel wheels w/painted center ornaments
- Black painted steel front bumper w/grained mold-in-color top cover
- Black painted rear bumper
- Black lower air dam
- Front fender vents
- Box-rail & tailgate top-edge moldings
- Black painted grille
- Sealed beam halogen headlamps
- Pickup box/cargo lights
- Manual telescoping trailer tow mirrors w/manual glass
- Solar tinted glass
- Interval windshield wipers
- Front license plate bracket
- Rear license plate bracket
- Black Door Handles
- Removable locking tailgate w/black handle & Tailgate Assist
- Black vinyl full-floor covering
- Carpet delete
- Color-keyed scuff plates
- Black instrumentation -inc: tachometer, speedometer, oil pressure, coolant temp, fuel gauge, indicator lights, message center w/odometer, trip odometer, engine hour meter, warning messages, voltmeter, distance-to-empty, average fuel economy
- Securilock anti-theft ignition
- (4) air registers w/positive shut-off
- Auxiliary pwr point
- Dash-top tray
- Glove Box
- Instrument panel mounted storage bin & trash bag hook
- Color-keyed molded door trim panel-inc: hard armrest, grab handle, reflector
- Color-keyed cloth headliner
- Front passenger-side roof ride handle
- Driver & passenger grab handles
- Dual color-keyed cloth sunvisors-inc: driver-side pocket, passenger-side mirror insert
- Door operated dome lamp w/time delay off & IP switch
- Map lamps
- Dual color-keyed coat hooks
- Driver & front passenger airbags w/passenger-side deactivation switch
- SOS post crash alert system -inc: doors unlock, horn & hazard flashers are activated when air bags are deployed
- Color-keyed safety belts w/height adjustable D-rings
- BeltMinder seatbelt-not-buckled chime & flashing warning light
- Child seat tethers on passenger seat
- Tire pressure monitoring system
- Cold Cranking Amps @ 0° F (Primary): 650
- Maximum Alternator Capacity (amps): HD 157
- Maximum Alternator Watts: 1950
- Total Cooling System Capacity (qts): 27.5
- Total Cooling System Capacity (qts): 26.4
- Gross Axle Wt Rating - Front (lbs): 4400
- Gross Axle Wt Rating - Front (lbs): 4400
- Gross Axle Wt Rating - Rear (lbs): 6100
- Curb Weight - Front (lbs): 3690
- Curb Weight - Front (lbs): 3557
- Curb Weight - Rear (lbs): 2487
- Curb Weight - Rear (lbs): 2487
- Gross Vehicle Weight Rating Cap (lbs): 9200
- Gross Vehicle Weight Rating Cap (lbs): 9000
- Gross Combined Wt Rating (lbs): 17000
- Dead Weight Hitch - Max Trailer Wt. (lbs): 5000
- Dead Weight Hitch - Max Tongue Wt. (lbs): 500
- Wt Distributing Hitch - Max Trailer Wt. (lbs): 12500
- Wt Distributing Hitch - Max Trailer Wt. (lbs): 10800
- Wt Distributing Hitch - Max Tongue Wt. (lbs): 1875
- Wt Distributing Hitch - Max Tongue Wt. (lbs): 1620
- Fifth Wheel Hitch - Max Trailer Wt. (lbs): 10800
- Fifth Wheel Hitch - Max Tongue Wt. (lbs): 2700
- Suspension Type - Front: Coil
- Suspension Type - Rear: 2-Stage Leaf
- Spring Capacity - Front (lbs): 4000
- Spring Capacity - Rear (lbs): 6100
- Axle Type - Front: Dana Super 60 Monobeam
- Axle Type - Rear: Visteon Full-Floating
- Axle Capacity - Front (lbs): 6000
- Axle Capacity - Rear (lbs): 6200
- Axle Ratio (:1) - Front: 4.10
- Axle Ratio (:1) - Rear: 4.10
- Shock Absorber Diameter - Front (mm): 35
- Shock Absorber Diameter - Rear (mm): 35
- Stabilizer Bar Diameter - Front (in): 1.10
- Stabilizer Bar Diameter - Rear (in): 0.63
- Brake Type: Pwr
- Brake ABS System: 4-Wheel
- Disc - Front (Yes or ): Yes
- Disc - Rear (Yes or ): Yes
- Front Brake Rotor Diam x Thickness (in): 13.66 x 0.58
- Rear Brake Rotor Diam x Thickness (in): 13.39 x 0.47
- Front Tire Order Code: TBK
- Rear Tire Order Code: TBK
- Spare Tire Order Code: TBK
- Front Tire Size: LT245/75R17E
- Rear Tire Size: LT245/75R17E
- Spare Tire Size: LT245/75R17E
- Front Tire Capacity (lbs): 3195
- Rear Tire Capacity (lbs): 3195
- Spare Tire Capacity (lbs): 3195
- Revolutions/Mile @ 45 mph - Front: 664
- Revolutions/Mile @ 45 mph - Rear: 664
- Revolutions/Mile @ 45 mph - Spare: 664
- Front Wheel Size (in): 17 x 7.5
- Rear Wheel Size (in): 17 x 7.5
- Spare Wheel Size (in): 17 x 7.5
- Front Wheel Material: Steel
- Rear Wheel Material: Steel
- Spare Wheel Material: Steel
- Steering Type: Pwr
- Steering Ratio (:1), On Center: 17.0
- Steering Ratio (:1), At Lock: - TBD -
- Turning Diameter - Curb to Curb (ft): 46.1
- Turning Diameter - Wall to Wall (ft): 48.0
- Fuel Tank Capacity, Approx (gal): 38
- Fuel Tank Location: Midship
- Wheelbase (in): 137.0
- Length, Overall w/o rear bumper (in): 227.0
- Width, Max w/o mirrors (in): 79.9
- Height, Overall (in): 78.5
- Overhang, Front (in): 37.6
- Overhang, Rear w/o bumper (in): 52.4
- Front Bumper to Back of Cab (in): 118.9
- Cab to Axle (in): 56.3
- Cab to End of Frame (in): 96.6
- Ground to Top of Load Floor (in): 34.6
- Ground to Top of Frame (in): - TBD -
- Frame Width, Rear (in): 36.5
- Ground Clearance, Front (in): - TBD -
- Ground Clearance, Rear (in): 8.1
- Cargo Box Length @ Floor (in): 98.0
- Cargo Box Width @ Top, Rear (in): 63.6
- Cargo Box Width @ Floor (in): 60.6
- Cargo Box Width @ Wheelhousings (in): 50.9
- Cargo Box (Area) Height (in): 20.0
- Tailgate Width (in): 60.6
- Cargo Volume (ft³): 77.4
- Passenger Capacity: 3
- Front Head Room (in): - TBD -
- Front Leg Room (in): - TBD -
- Front Shoulder Room (in): - TBD -
- Front Hip Room (in): - TBD -
- Vehicle Name: Ford Super Duty F-250 SRW
- Body Style: Reg Cab 8'
- Body Code: 137" WB
