- Pickup bed
- Automatic Stop/Start
- Transfer case, single speed, electronic Autotrac with push button control (4WD models only)
- Four wheel drive
- Frame, fully-boxed, hydroformed front section
- Recovery hooks, front, frame-mounted, Black
- Cargo tie downs (12), fixed, rated at 500 lbs per corner
- Steering, Electric Power Steering (EPS) assist, rack-and-pinion
- Brakes, 4-wheel antilock, 4-wheel disc with DURALIFE rotors
- Capless Fuel Fill
- Exhaust, single outlet
- Exhaust, aluminized stainless-steel muffler and tailpipe
- Wheels, 20" x 9" (50.8 cm x 22.9 cm) Black gloss painted aluminum
- Tires, 275/60R20 all-season, blackwall
- Wheel, 17" x 8" (43.2 cm x 20.3 cm) full-size, steel spare
- Tire, spare 255/80R17SL all-season, blackwall (Included and only available with 20" or 22" wheels and tires.)
- Tire carrier lock keyed cylinder lock that utilizes same key as ignition and door
- Bumper, front, body-color lower (Front bumper color will be high gloss black.)
- Bumper, rear body-color with corner steps
- CornerStep, rear bumper
- Grille (Body-color surround with high gloss Black mesh and inserts.)
- Headlamps, LED reflector with incandescent turn signals and LED signature Daytime Running Lamps
- Fog lamps, LED
- Taillamps, LED tail and stop light with incandescent reverse light
- Mirrors, outside heated power-adjustable
- Glass, deep-tinted
- Lamps, cargo area, cab mounted integrated with center high mount stop lamp, with switch in bank on left side of steering wheel.
- LED Cargo Area Lighting located in cargo box activated with switch on center switch bank or key fob
- Tailgate, standard
- Tailgate, gate function manual with EZ Lift includes power lock and release, includes hitch area light
- Tailgate and bed rail protection caps, top
- Door handles, body-color
- Audio system, GMC Infotainment System with 8" diagonal color touch-screen, AM/FM stereo with seek-and-scan and digital clock, includes Bluetooth® streaming audio for music and select phones; featuring Android Auto and Apple CarPlay capability for compatible phones
- Audio system feature, 6-speaker system
- Bluetooth® for phone connectivity to vehicle infotainment system
- Steering wheel audio controls
- 4G LTE Wi-Fi Hotspot capable (Terms and limitations apply. See onstar.com or dealer for details.)
- Seats, front 40/20/40 split-bench with covered armrest storage and under-seat storage (lockable) (Not available with (PCU) Elevation Convenience Package with Bucket Seats.)
- Seat adjuster, driver 4-way manual
- Seat adjuster, passenger 4-way manual
- Seat, rear 60/40 folding bench (folds up), 3-passenger (includes child seat top tether anchor)
- Floor covering, color-keyed carpeting
- Floor mats, rubberized-vinyl front (Deleted when (RIA) All-weather floor liner, LPO is ordered.)
- Floor mats, rubberized-vinyl rear (Deleted when (RIA) All-weather floor liner, LPO is ordered.)
- Steering column, Tilt-Wheel, manual with wheel locking security feature
- Steering wheel, leather-wrapped
- Driver Information Center, 4.2" diagonal color display includes driver personalization
- Compass, located in instrument cluster
- Exterior Temperature Display, located in radio display
- Brake lining wear indicator
- Windows, power front, drivers express up/down
- Window, power front, passenger express down
- Windows, power rear, express down
- Door locks, power
- Remote vehicle starter system
- Keyless Open and Start
- Cruise control, steering wheel-mounted
- Theft-deterrent system, unauthorized entry
- Steering column, lock control, electrical
- USB ports, 2 (first row) located on instrument panel
- Power outlet, front auxiliary, 12-volt
- USB ports, dual, charge-only (2nd row)
- Power outlet, rear auxiliary, 12-volt
- Air conditioning, single-zone manual, semi-automatic
- Air vents, rear
- Defogger, rear-window electric
- Mirror, inside rearview, manual tilt
- Assist handles front A-pillar mounted for driver and passenger, rear B-pillar mounted
- GMC Connected Access capable (Subject to terms. See onstar.com or dealer for details.)
- StabiliTrak, stability control system with Proactive Roll Avoidance and traction control, includes electronic trailer sway control and hill start assist
- Daytime Running Lamps LED signature lighting
- Airbags, Dual-stage frontal airbags for driver and front outboard passenger; Seat-mounted side-impact airbags for driver and front outboard passenger; Head-curtain airbags for front and rear outboard seating positions; Includes front outboard Passenger Sensing System for frontal outboard passenger airbag (Always use seat belts and child restraints. Children are safer when properly secured in a rear seat in the appropriate child restraint. See the Owner's Manual for more information.)
- OnStar and GMC connected services capable (Terms and limitations apply. See onstar.com or dealer for details.)
- Rear Vision Camera
- Teen Driver mode a configurable feature that lets you activate customizable vehicle settings associated with a key fob, to help encourage safe driving behavior. It can limit certain available vehicle features, and it prevents certain safety systems from being turned off. An in-vehicle report card gives you information on driving habits and helps you to continue to coach your new driver
- Tire Pressure Monitoring System with Tire Fill Alert (does not apply to spare tire)
- Rear Seat Reminder
- Fuel Economy Est-Combined (MPG): 24
- Fuel Economy Est-Combined (MPG): 20
- EPA Fuel Economy Est - City (MPG): 22
- EPA Fuel Economy Est - City (MPG): 19
- EPA Fuel Economy Est - Hwy (MPG): 26
- EPA Fuel Economy Est - Hwy (MPG): 22
- Cold Cranking Amps @ 0° F (Primary): 850
- Cold Cranking Amps @ 0° F (Primary): 730
- Maximum Alternator Capacity (amps): 220
- Maximum Alternator Watts: - TBD -
- Total Cooling System Capacity (qts): - TBD -
- Gross Axle Wt Rating - Front (lbs): 3800
- Gross Axle Wt Rating - Rear (lbs): 3800
- Curb Weight - Front (lbs): 2849
- Curb Weight - Rear (lbs): 1986
- Gross Vehicle Weight Rating Cap (lbs): 7000
- Gross Combined Wt Rating (lbs): 15000
- Gross Combined Wt Rating (lbs): 12000
- Dead Weight Hitch - Max Trailer Wt. (lbs): 5000
- Dead Weight Hitch - Max Tongue Wt. (lbs): 500
- Wt Distributing Hitch - Max Trailer Wt. (lbs): 9000
- Wt Distributing Hitch - Max Trailer Wt. (lbs): 6600
- Wt Distributing Hitch - Max Tongue Wt. (lbs): 900
- Wt Distributing Hitch - Max Tongue Wt. (lbs): 660
- Fifth Wheel Hitch - Max Trailer Wt. (lbs): 7000
- Fifth Wheel Hitch - Max Trailer Wt. (lbs): 6600
- Fifth Wheel Hitch - Max Tongue Wt. (lbs): 1750
- Fifth Wheel Hitch - Max Tongue Wt. (lbs): 1650
- Maximum Trailering Capacity (lbs): 11100
- Suspension Type - Front: Independent
- Suspension Type - Rear: Solid Axle
- Spring Capacity - Front (lbs): 3800
- Spring Capacity - Rear (lbs): 3850
- Axle Type - Front: - TBD -
- Axle Type - Rear: - TBD -
- Axle Capacity - Front (lbs): 3800
- Axle Capacity - Rear (lbs): 3800
- Axle Ratio (:1) - Front: 3.42
- Axle Ratio (:1) - Rear: 3.42
- Shock Absorber Diameter - Front (mm): 50
- Shock Absorber Diameter - Rear (mm): 50
- Stabilizer Bar Diameter - Front (in): 1.30
- Brake Type: Pwr
- Brake ABS System: 4-Wheel
- Disc - Front (Yes or ): Yes
- Disc - Rear (Yes or ): Yes
- Front Brake Rotor Diam x Thickness (in): 13.5 x 1.18
- Rear Brake Rotor Diam x Thickness (in): 13.6 x 0.79
- Front Tire Order Code: QAB
- Rear Tire Order Code: QAB
- Spare Tire Order Code: QAQ
- Front Tire Size: 275/60R20
- Rear Tire Size: 275/60R20
- Spare Tire Size: 255/80R17SL
- Front Tire Capacity (lbs): - TBD -
- Rear Tire Capacity (lbs): - TBD -
- Spare Tire Capacity (lbs): - TBD -
- Revolutions/Mile @ 45 mph - Front: - TBD -
- Revolutions/Mile @ 45 mph - Rear: - TBD -
- Revolutions/Mile @ 45 mph - Spare: - TBD -
- Front Wheel Size (in): 20 x 9.0
- Rear Wheel Size (in): 20 x 9.0
- Spare Wheel Size (in): 17 x - TBD -
- Front Wheel Material: Aluminum
- Rear Wheel Material: Aluminum
- Spare Wheel Material: Steel
- Steering Type: Electric Rack & Pinion
- Steering Ratio (:1), On Center: - TBD -
- Steering Ratio (:1), At Lock: - TBD -
- Turning Diameter - Curb to Curb (ft): 46.9
- Turning Diameter - Curb to Curb (ft): 46.3
- Turning Diameter - Wall to Wall (ft): - TBD -
- Fuel Tank Capacity, Approx (gal): 24
- Fuel Tank Location: - TBD -
- Wheelbase (in): 147.43
- Length, Overall (in): 231.72
- Width, Max w/o mirrors (in): 81.24
- Height, Overall (in): 75.51
- Overhang, Front (in): - TBD -
- Overhang, Rear w/o bumper (in): - TBD -
- Front Bumper to Back of Cab (in): - TBD -
- Cab to Axle (in): - TBD -
- Cab to End of Frame (in): - TBD -
- Ground to Top of Load Floor (in): - TBD -
- Ground to Top of Frame (in): - TBD -
- Frame Width, Rear (in): - TBD -
- Ground Clearance, Front (in): 8.09
- Ground Clearance, Rear (in): 8.09
- Cargo Box Length @ Floor (in): 69.92
- Cargo Box Width @ Top, Rear (in): - TBD -
- Cargo Box Width @ Floor (in): 71.4
- Cargo Box Width @ Wheelhousings (in): 50.63
- Cargo Box (Area) Height (in): 22.4
- Tailgate Width (in): - TBD -
- Cargo Volume (ft³): 62.9
- Ext'd Cab Cargo Volume (ft³): - TBD -
- Passenger Capacity: 6
- Front Head Room (in): 43.03
- Front Leg Room (in): 44.53
- Front Shoulder Room (in): 66.02
- Front Hip Room (in): 61.18
- Second Head Room (in): 40.12
- Second Leg Room (in): 43.4
- Second Shoulder Room (in): 65.16
- Second Hip Room (in): 60.24
- Vehicle Name: GMC Sierra 1500
- Body Style: Crew Cab Pickup
- Body Code: E63
- EPA Greenhouse Gas Score: - TBD -
- Tons/yr of CO2 Emissions @ 15K mi/year: 8.7
- Tons/yr of CO2 Emissions @ 15K mi/year: 8.9
